Product Details
Place of Origin: china
Brand Name: HUAKE
Certification: CE
Model Number: Y81-125
Payment & Shipping Terms
Minimum Order Quantity: 1 Piece
Packaging Details: EXPORT WORTHY PACKAGE
Delivery Time: 35-40 DAYS
Payment Terms: L/C, T/T
Supply Ability: 300sets Per Year
Transport Package: |
Export Worthy Package |
Specification: |
125 Tons Main Cylinder Side Titli |
Bale Discharge: |
Side Titling Out |
HS Code: |
84629190 |
Additional Design: |
Can Add A Hopper To Preload Material While The Baler Work |
Press Box Size: |
1150X700X600mm Or Buyers Preference |
Bale Size: |
250X250 Octagon 230 Octagon 260 |
Bale Weight: |
30-50kg |
Motor: |
15 Kw |
Certification: |
Ce SGS |
Function: |
Scrap Metal Baling |
Bale Weight: |
20-30kg |
Transport Package: |
Export Worthy Package |
Specification: |
125 Tons Main Cylinder Side Titli |
Bale Discharge: |
Side Titling Out |
HS Code: |
84629190 |
Additional Design: |
Can Add A Hopper To Preload Material While The Baler Work |
Press Box Size: |
1150X700X600mm Or Buyers Preference |
Bale Size: |
250X250 Octagon 230 Octagon 260 |
Bale Weight: |
30-50kg |
Motor: |
15 Kw |
Certification: |
Ce SGS |
Function: |
Scrap Metal Baling |
Bale Weight: |
20-30kg |
| Model | Main Cyl.Force | Press Box Size | Bale Size | Bale Weight | Motor |
| (ton) | (mm) | (mm) | (kg) | (kW) | |
| Y81F-125A | 125 | 1100x700x550 | 200x200 Octagon | 15-35 | 15 |
| 140 Octagon 200 | |||||
| Y81F-125B | 125 | 1100x700x600 | 230x230 | 25-40 | 15 |
| Y81F-125C | 125 | 1150x700x600 | 250x250 Octagon | 30-50 | 15 |
| 230 Octagon 260 | |||||
| Y81F-125D | 125 | 1200x700x600 | 300x300 | 50-70 | 15 |
| Y81F-125E | 125 | 1200x800x600 | 300x300 | 50-70 | 15 |
| Y81F-125F | 125 | 1200x900x600 | 300x300 | 50-70 | 15/22 |
| Octagon 260 | |||||
| Y81F-125G | 125 | 1400x700x700 | 300x300 | 60-90 | 22 |
| Y81F-125H | 125 | 1400x800x700 | 300x300 | 60-90 | 22 |
| Octagon 300 | |||||
| Y81F-125J | 125 | 1400x900x600 | Octagon 260 | 60-90 | 22 |
| Octagon 300 |
quality guaranne
Main welded Frame: Sturdy and durable with more than 10 years warranty.
Main Cylinder: Domestic famous engines, strong driving force.
Good quality hydraulic oil cylinder with 7 years warranty.
Advance PLC System: Omron Japan
Package: Seaworthy package for (Film package,Naked package or Shrink-pack).
24 hours online service
Enquiry will be replied in 2 hours
One year guarantee and lifelong maintenance.
Spare parts: supply one set of spare parts for free, tool box, operation book.
Free parts for any breakdown with convincing evidence
Any problem, you can call usdirectly.
Features:
a) Hydraulic drive, manual valve operation or PLC control for choice..
b) Bale-discharging for choice: "turn-out", "push-out", "forward-out" & manual discharging.
c) Options for different force, press box size, bale shape & size
d)Electrical motor, diesel engine or generator for power.
Applications:
Y81 series of hydraulic scrap balers are applied in steel mills, recycling plants, ferrous & non
-ferrous smelting industry to press scrap metal (steel, copper, aluminum, stainless steel, discarded automobiles, etc)
into acceptable furnace charges in shape of cuboids, cylinders & octagons
